| Operation Class | Class D |
| Number of Channels | 01 |
| Maximum Power | @ 14,4 VDC - 0,5 Ohm: 3000 Watts RMS
@ 14,4 VDC - 1 Ohm: 3000 Watts RMS
@ 14,4 VDC - 2 Ohms: 3000 Watts RMS
@ 14,4 VDC - 4 Ohms: 1700 Watts RMS |
| Input Sensitivity | 4V ~ 0,2V |
| Frequency Response | 8Hz ~ 200KHz (-3dB) |
| Crossover High Pass (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| Crossover Low Pass(LPF) | 60Hz ~ 200KHz (-12dB/8ª) Variable |
| Protection System | Output short-circuit, low/high supply voltage, thermal protection |
| Maximum Music Consumption | 190A |
| Maximum Consumption in Sinusoidal Signal | 278A |
| Dimensions(W X H X L) | 9.37" x 2.80" x 9.45" |
| Weight | 7.51 |
